Colorcoat SDP50 Matt Matehe
Manual
Colorcoat SDP 50
COLORCOAT® SDP 50

Colorcoat® SDP 50 is an aesthetic, durable and resilient pre-painted steel with a long guaranteed life expectancy. The substrate is continuous galvanised steel and a high performance organic coating with a layer thickness of 50 µm. It is the perfect material for profiles and sandwich panels for walls and roofs of premium architectural projects. Colorcoat SDP 50 is available in a variety of popular standard roof and wall colours, including an attractive range of metallic colours with a sparkling effect.

Examples of buildings with Colorcoat SDP 50 are the Frontier building in Delft, The Netherlands or the AFAS stadium.

Colorcoat SDP 50 is guaranteed for use with solar panels for up to 25 years.

AZ Stadium - Colorcoat SDP 50
Manual
Colorcoat SDP 50 Matt
COLORCOAT® SDP 50 Matt

A high build pre-painted steel with a matt finish and a robust textured surface.

The substrate is galvanised with a zinc or MagiZinc metallic coating which provides excellent corrosion resistance. The 50 µm textured coating provides an improved scratch and abrasion resistance. Colorcoat® SDP 50 Matt is well suited for roofing applications but also provides outstanding aesthetics in wall applications. The high performance reverse side backing coat is especially formulated for use in construction applications.

This product is available in all the popular roofing colours including Matt Black.

Colorcoat® SDP 50 Matt has a Tata Steel Performance Guarantee up to 25 years.

Colorcoat SDP 50 Matt
Manual
Colorcoat SDP 35
COLORCOAT® SDP 35

Colorcoat® SDP 35 is a robust pre-painted steel for roof and wall cladding including a galvanised substrate with Zinc or Magizinc coating, with a grainy and textured low surface. Colorcoat SDP 35 has an organic coating with a layer thickness of 35 µm.

Typical applications are outdoor applications where robustness is important, this product is often used for walkable roofs with low slopes.

Colorcoat SDP 35 has a Tata Steel Performance Guarantee up to 15 years.

Colorcoat SDP 35 Matt T
Manual
Colorcoat PE 25
COLORCOAT® PE 25

Colorcoat® PE 25 has a substrate of continuously galvanised steel with a smooth coating based on a polyester resin. The product is suitable for application in non-aggressive outdoor environments. The topside coating has a layer thickness of 25 µm. High performance reverse side backing coat specially formulated for use in construction applications.

Typical applications are plank profiles, roof tile sheets, roof and wall sandwich A-side and roof and wall trapezoidal or sinus profiles.

Colorcoat PE 25 has a Tata Steel Performance guarantee up to 10 years.



COLORCOAT® PE 25
Manual
Colorcoat PE 15
COLORCOAT® PE 15

Colorcoat PE 15 / Interior coating has a polyester base and a colour close to RAL 9002 (grey-white) or 9010 (white). Due to the high light reflection, savings can be made on lighting costs and thus energy bills, this makes a positive contribution to the sustainability of buildings.

The backcoat is light-coloured. Colorcoat PE 15 is mainly used on the interior side of sandwich panels, on the visible side of liner trays and on (profiled) decking roof panels.

Colorcoat PE 15 is not suitable for external use.

Colorcoat PE15 applications
Manual
Colorcoat PVDF 35
Colorcoat® PVDF 35

Colorcoat® PVDF 35 is used for the envelope exterior of the building, such as profiles, panels and façade elements for which the colour stability and colour gloss retention are important.

Colorcoat PVDF 35 is available up on request.

Manual
Colorcoat PVDF
Colorcoat® PVDF

Colorcoat® PVDF is used to building envelope applications such as wall cladding and panels, where colour and gloss retention are important.

Typical applications are walls and buildings where the aesthetics are important.

Colorcoat PVDF is available up on request.

COLORCOAT® PVDF
